Auramax VP 4, D 100 90-00039 [11/32] Attention

Сorrect use

Axial duct domestic electric fan, axial duct domestic removable electric fan is

designed to remove odors and excess moisture from toilets, bathrooms and other

small rooms, required ventilation.

Attention!

Children of 8 years old and upward intend this appliance for use and

persons with reduced physical, sensory or mental capabilities, or lack

of knowledge, unless a person responsible for their safety has given

them supervision or instruction concerning the use of the appliance.

Children should be supervised to ensure that they do not play with

the appliance. Cleaning and service of the device shouldn’t to be

made by children without supervision.

Safety requirements

Base on type of protection from electric shock the fans relate to the devices of

class ll (220-240V ~ 50/60 Hz). When connecting the fans to the AC mains with a

frequency of 60 Hz, the technical characteristics may change. Check them with

the manufacturer. The climate category «moderately cold» Type «4» (УХЛ4). The

level of protection against solid objects and water is IP 24. The IP level is ensured

if the device is installed in the normal operating position.

Attention!

• Specialists, who have a special allowance for such types of work,

shall do connection of the fans to power supply. The temperature of fan

exploitation cannot exceed the indicated range (from +1C to +40C).

• Avoid the installation of the fan to one ventilation main line with

smoke-deﬂecting pipe from devices, having fuel burners. In case of

maintenance diagnostics, turn o the automatic breaker (S1 in OFF

position) and call an electrician.

• For the purposes of maintenance or complete replacement of the

equipment, all fans must have detachable ﬁxing.

Attention!

All actions for connection, set up, maintenance and repair of the

product have to be carried out only at mains voltage removed (S1 in

OFF position).

One-phase main, to which the fan is connected, must correspond to the norms in

force. Stationary electric wiring must be equipped with an automatic circuit breaker

(S1 in the scheme). The connection is carried out through the switch (S2 in the

diagram) that is built into the stationary wiring. The gap between switch contacts

at all poles must be not less than 3 mm. In the option «-02» the switch (S3 on the

scheme) is built in the fan. Before installation, it is necessary to make sure that there

is no visible damage of impeller, case, grill, and the ﬂow passage of the case has no

any extraneous things, which may damage impeller blades.

Before using the appliance please read the contents of this

instruction.
