3. Components
1) Common Components
Thermal Grease
[ZM-STG2]
Loading Block
Nuts
Double-sided Tape
Backplate
PWM Mate
Extension Cable
User’s Manual
Cooler
Side Caps
Wrench
Silver Bolts B (3mm)
(Socket 1156/1155/775/AMD)
Silver Bolts A (4mm)
(Socket 2011)
Gold Bolts
(Socket 1366 )
AMD Clip
Intel Clip
2) Intel Components 3) AMD Components
Socket 2011/1366/1156/1155/775 Socket FM2/FM1/AM3+/AM3/AM2+/AM2
