Zalman CNPS10X Extreme [10/12] Caution
![Zalman CNPS10X Extreme [10/12] Caution](/views2/1111007/page10/bga.png)
10
.COM
③
Remove the Sticker Cover from the Lower Tier of the Loading Block
and attach to the Backplate.
Caution
Please make note of the orientation of the Loading Block’s Installation.
Attach Double-sided Tape to the Loading Block and remove
the Double-sided Tape Cover.
Loading Block
Double-sided Tape
O
X
④
Disassemble the motherboard’s Clip Support.
M/B
M/B
