Socket 775 Installation
Remove the Sticker Cover from the Lower Tier of the Loading Block
and attach
to the Backplate.
Attach Double-sided Tape to the Loading Block and remove
the Double-sided Tape Cover.
Double-sided Tape
Loading Block
X
O
Caution
Please make note of the orientation of the Loading Block’s Installation.
