RESERATOR 1

www.zalman.co.kr www.zalmanusa.com

1.1 Reserator (Reservoir + Radiator + Water Pump)

Reserator is a compound word derived from ‘Reservoir’ and

‘Radiator’- it acts as a reservoir while radiating heat. This product

works well with natural convection and integrates a water pump

inside for convenience.

1.2 CPU Water Block(ZM-WB2 Gold)

The system includes Zalman’s new CPU cooling component,

ZM-WB2 Gold, which performs superbly and installs easily.

1.3 Flow Indicator

This component is connected in-line with the circulation tube to

check the circulation of the coolant. When the coolant is actively

circulating, the cap inside the flow indicator shakes rapidly,

providing easy indication of the circulation status.

2.1 Reserator (Reservoir + Radiator + Water Pump)

Dissipation Area : 1.274 ㎡

Weight : 6.5kg

Dimensions : 150(L) x 150(W) x 592(H) mm

Material : Anodized Pure Aluminum

Coolant Capacity : 2.5ℓ Maximum

Integrated Water Pump : 5 W, Qmax 300ℓ/h(A type : 220 V-60 Hz, B type : 230 V-50 Hz,

C type : 120 V-60 Hz, D type : 110 V-60 Hz)

Maximum Lift : 0.5 m

2.2 CPU Water Block(ZM-WB2 Gold)

Weight : 447g

Material : Pure Aluminum Cover, Gold-Plated Pure Copper Base

Dimensions : 64 x 31mm

Compatibility : Intel Pentium 4 (Socket 478), AMD Athlon / Duron / Athlon XP (Socket 462),

AMD AMD64 (Athlon 64 / Athlon 64 FX / Opteron) (Socket 754 / 940)

2. Specifications
