• Press
to clear the message and continue printing.
Note: If no paper is loaded in the feeder when
is selected, then the printer automatically
overrides the request, and then prints from an automatically selected tray.
• Cancel the current job.
Load manual feeder with [paper size] [paper orientation]
Try one or more of the following:
• Load the multipurpose feeder with the correct size of paper.
• Press
to clear the message and continue printing.
Note: If no paper is loaded in the feeder when
is selected, then the printer manually overrides
the request, and then prints from an automatically selected tray.
• Cancel the current job.
Load manual feeder with [paper type] [paper size] [paper orientation]
Try one or more of the following:
• Load the multipurpose feeder with the correct size and type of paper.
• Press
to clear the message and continue printing.
Note: If no paper is loaded in the feeder when
is selected, then the printer manually overrides
the request, and then prints from an automatically selected tray.
• Cancel the current job.
Maintenance kit low [80.xy]
You may need to order a maintenance kit. If necessary, select Continue to clear the message and
continue printing. Press
to confirm.
Maintenance kit nearly low [80.xy]
If necessary, select Continue to clear the message and continue printing. Press to confirm.
Maintenance kit very low, [x] estimated pages remain [80.xy]
You may need to replace the maintenance kit very soon.
