Develop ineo 4700P [16/217] User s guide

User's Guide

- 16 -

Right side

110 mm (4.33 in.)

Front

305 mm (12 in.)

Left side

65 mm (2.56 in.)

Rear

100 mm (3.94 in.)

5 Top 305 mm (12 in.)
