Develop ineo 4700P [171/217] Jammed pages are not reprinted
![Develop ineo 4000P [171/217] Jammed pages are not reprinted](/views2/1116621/page171/bgab.png)
User's Guide
- 171 -
Paper jam message remains after jam is cleared
Action
Yes
No
1. Do either of the following:
- Select Next > >Clear the jam, press OK > .
2. Follow the instructions on the printer display.
Does the paper jam message remain?
Contact technical
support.
The problem is
solved.
Jammed pages are not reprinted
Action
Yes
No
1. Turn on jam recovery.
a. From the printer control panel, navigate to:
Settings >General Settings >Print Recovery >Jam
Recovery
b. Select On or Auto.
c. Depending on your printer model, press
or touch
Submit.
2. Resend the pages that did not print.
Were the jammed pages reprinted?
The problem is
solved.
Contact technical
support.
