48
ENGLISH
EN
1. Press the pedal forward
the machine moves forward.
2. No load on the pedal – the
machine is stationary.
3. Press the pedal backward
the machine reverses.
4. Reduce the pressure on the
pedal – the machine brakes.
2.4.10Adjustable steering wheel (14 HST,
Silent)
The height of the steering wheel is infinitely
adjustable. Undo the adjustment knob (3:H) on the
steering column and raise or lower the steering
wheel to the desired position. Tighten.
Do not adjust the steering wheel during
operation.
Never turn the steering wheel when the
machine is stationary with a lowered
implement. There is a risk of abnormal
loads on the servo and steering
mechanisms.
2.4.11 Cutting height adjustment (3:I)
(Silent)
The machine is equipped with a control for using
the cutting deck with electrical cutting height
adjustment.
The switch is used to adjust the cutting
height in continuously variable positions.
The cutting deck is connected to the contact (3:Z).
2.4.12 Seat (4:L)
The seat can be folded and adjusted
forwards and backwards. The seat’s
forward/backward position can be locked
with the knobs (4:M).
The seat is equipped with a safety switch that is
connected to the machine’s safety system. This
means that certain activities that can entail danger
cannot be carried out when nobody is sitting in the
seat. See also 4.3.2.
2.4.13 Engine casing (fig. 5)
To fill with fuel and to inspect and maintain the
engine and battery, open the engine casing.
The engine must not be running when
the casing is opened.
2.4.13.1Opening
1. Ensure that the control arms are in their forward
positions.
2. Raise the seat lock (4:N) and fold the seat
forwards.
3. Grasp the front edge of the engine casing and
fold up the casing (fig. 3).
2.4.13.2Closing
Grasp the front edge of the engine casing and fold
down the casing.
The machine may not be operated
unless the engine casing is folded down.
Risk of burns and crushing injuries.
2.4.14 Clutch release lever (6:K) (HST)
A lever for disengaging the variable transmission.
Enables the machine to be moved by hand without
the help of the engine.
The disengagement lever must never be
between the outer and inner positions.
This overheats and damages the
transmission.
Two positions:
1. Lever in– transmission
engaged for normal operation.
There is an audible click when
the lever locks in the outer
position.
2. Lever out– transmission disengaged. The
machine can be moved by hand.
The machine may not be towed over long distances
or at high speeds. The transmission could be
damaged.
