50
ENGLISH
EN
4.3 SAFETY CHECKS
Check that the results of the safety checks below
are achieved when testing the machine in question.
The safety checks must always be
carried out every time before use.
If any of the results below is not
achieved, the machine must not be
used! Take the machine to a service
workshop for repair.
4.3.1 General safety check
4.3.2 Electrical safety check
The operation of the safety system
should always be checked every time
before use.
4.4 START
1. See fig. 10 (+9:T). Open the fuel cock located
inside the cover on the rear left-hand side.
2. Check that the spark plug cable(s) is/are
installed on the spark plug(s).
3. Check to make sure that the power take-off is
disengaged.
4. Do not keep your foot on the drive pedal.
5. Starting cold engine – put the throttle control in
the choke position.
Starting warm engine – put the throttle control
at full throttle (approx. 2 cm behind the choke
position).
6. Depress the clutch-brake pedal fully.
7. Turn the ignition key and start the engine.
8. Once the engine has started, move the throttle
control gradually to full throttle (approx. 2 cm
behind the choke position) if the choke has been
used.
9. When starting from cold, do not make the
machine work under load immediately, but let
the engine run for a few minutes first. This will
allow the oil to warm up.
When the machine is in operation, full throttle
should always be used.
4.5 OPERATING TIPS
Always check that there is the correct volume of
oil in the engine. This is particularly important
when operating on slopes. See 4.2.
Be careful when driving on slopes. No
sudden starting or stopping when
driving up or down a slope. Never drive
across a slope. Move from the top down
or from the bottom to the top.
The machine may not be driven on
slopes greater than 10º in any direction.
Reduce the speed on slopes and when
making sharp turns in order to retain
control and reduce the risk of tipping
over.
Do not turn the steering wheel to full
lock when driving in top gear and at full
throttle. The machine can easily topple
over.
Keep hands and fingers well away from
articulated steering joint and seat
bracket. Risk of crushing injuries.
Never drive with the engine casing
open.
Never drive with the deck connected in
the transport position. This will damage
the deck’s drive belt.
Never drive with the deck connected in
the transport position. This will damage
the deck’s drive belt.
Object Result
Fuel lines and con-
nections.
No leaks.
Electrical cables. All insulation intact.
No mechanical damage.
Exhaust system. No leaks at connections.
All screws tightened.
Oil lines No leaks. No damage.
Drive the machine
forwards/back-
wards and release
the driving-service
brake pedal.
The machine will stop.
Test driving No abnormal vibrations.
No abnormal sound.
Status Action Result
The clutch-brake
pedal is not
depressed.
The power take-off
is not activated.
Try to start. The engine
will not start.
The clutch-brake
pedal is depressed.
The power take-off
is activated.
Try to start. The engine
will not start.
Engine running.
The power take-off
is activated.
The driver gets
up from the seat.
The engine
shall stop.
Engine running. Remove fuse. The engine
shall stop.
