3 - 12
CHK
ADJ
1
Order Job/Part Q’ty Remarks
Removing the headlight assembly
Remove the parts in the order listed.
1 Headlight assembly 1
For installation, reverse the removal
procedure.
COWLINGS AND COVERS
