Yamaha FJR1300(N) (2001) [510/617] Air induction system
![Yamaha FJR1300(N) (2001) [510/617] Air induction system](/views2/1121433/page510/bg1fe.png)
7 - 41
FI
AIR INDUCTION SYSTEM
EAS00509
AIR INDUCTION SYSTEM DIAGRAMS
1
Air cut-off valve
2
Reed valve
3
Air-filter case
È
To cylinder #4
É
To cylinder #3
Ê
To cylinder #2
Ë
To cylinder #1
12
4
3
