3 - 83
CHK
ADJ
ADJUSTING THE HEADLIGHT BEAMS
2. Adjust:
• headlight beam (horizontally)
▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼ ▼ ▼▼▼▼ ▼▼▼
a. Turn the adjusting screw 1 in direction a
or b.
Left headlight
Right headlight
▲▲▲▲ ▲ ▲▲▲▲ ▲ ▲▲▲▲ ▲ ▲▲▲▲ ▲ ▲▲▲▲ ▲ ▲▲▲▲ ▲▲▲
Direction
a
Headlight beam moves
to the right.
Direction
b
Headlight beam moves
to the left.
Direction
a
Headlight beam moves
to the right.
Direction
b
Headlight beam moves
to the left.
