Yamaha FJR1300(N) (2001) [377/617] Shift shaft
![Yamaha FJR1300(N) (2001) [377/617] Shift shaft](/views2/1121433/page377/bg179.png)
5 - 58
ENG
3. Install:
• shift arm 1
NOTE:
@
Align the punch mark a in the shift shaft with
the slot in the shift arm.
T
R
.
.
10 Nm (1.0 m · kg)
SHIFT SHAFT
