Yamaha TW200N (2000) [10/96] General specifications
![Yamaha TW200N (2000) [10/96] General specifications](/views2/1121455/page10/bga.png)
– 3 –
SPEC
GENERAL SPECIFICATIONS
* Load is the total weight of cargo, rider, passenger and accessories.
Basic weight:
With oil and full fuel tank 126 kg (278 lb)/(TW200EN), 127 kg (280 lb) (TW200ENC)
Maximum load* 157 kg (346 lb)/(TW200EN), 156 kg (344 lb) (TW200ENC)
Cold tire pressure: Front Rear
Up to 80 kg (176 lb) load* 125 kPa
(1.25 kg/cm
2
, 18 psi)
125 kPa
(1.25 kg/cm
2
, 18 psi)
80 kg (176 lb) ~ Maximum load* 150 kPa
(1.5 kg/cm
2
, 22 psi)
175 kPa
(1.75 kg/cm
2
, 25 psi)
Off-road riding 125 kPa
(1.25 kg/cm
2
, 18 psi)
125 kPa
(1.25 kg/cm
2
, 18 psi)
High speed riding 150 kPa
(1.5 kg/cm
2
, 22 psi)
175 kPa
(1.75 kg/cm
2
, 25 psi)
Brake:
Front brake type Single disc brake
Operation Right hand operation
Rear brake type Drum brake
Operation Right foot operation
Shock absorber:
Front shock absorber Coil spring/oil damper
Rear shock absorber Gas and coil spring/oil damper
Bulb wattage/quantity:
Headlight 12 V, 60 W/55 W
×
1
Tail/brake light 12 V, 8 W/27 W
×
2
Front turn signal/position light 12 V, 27 W/8 W
×
2
Rear turn signal light 12 V, 27 W
×
2
Meter light 12 V, 3.4 W
×
1
Model TW200EN/TW200ENC
