Yamaha TW200N (2000) [14/96] Maintenance specifications
![Yamaha TW200N (2000) [14/96] Maintenance specifications](/views2/1121455/page14/bge.png)
– 7 –
SPEC
MAINTENANCE SPECIFICATIONS
CHASSIS
Model TW200EN/TW200ENC
Steering system:
Steering bearing type Angular ball
Drive chain:
Type/manufacturer 428HG (I)/DAIDO
Number of links 121 links + joint
Chain free play 35 ~ 60 mm (1.38 ~ 2.36 in)
Front brake:
Brake type Single-disc brake
Disc outside diameter
×
thickness 220
×
3.5 mm (8.66
×
0.14 in)
Max. deflection 0.15 mm (0.006 in)
Brake pad lining thickness 5.3 mm (0.21 in)
<Limit> <0.8 mm (0.03 in)>
Master cylinder inside diameter 11 mm (0.43 in)
Caliper cylinder inside diameter 26.9 mm (1.06 in) + 22.2 mm (0.87 in)
Recommended fluid DOT4
Rear brake:
Brake type Drum brake (leading and trailing)
Drum inside dia. 110 mm (4.33 in)
<Limit> <111 mm (4.37 in)>
Lining thickness Front 4 mm (0.16 in)
<Limit> <2 mm (0.08 in)>
Shoe spring free length 50.5 mm (1.99 in)
Brake lever and brake pedal:
Brake lever free play (at lever end) 2 ~ 5 mm (0.08 ~ 0.20 in)
Brake pedal free play (at pedal end) 20 ~ 30 mm (0.8 ~ 1.2 in)
Brake pedal position 15 mm (0.6 in)
(Vertical height below footrest top.)
Clutch lever free play (at lever end): 10 ~ 15 mm (0.39 ~ 0.59 in)
