Yamaha TW200N (2000) [16/96] Maintenance specifications
![Yamaha TW200N (2000) [16/96] Maintenance specifications](/views2/1121455/page16/bg10.png)
– 9 –
SPEC
MAINTENANCE SPECIFICATIONS
ELECTRICAL
Model TW200EN/TW200ENC
C.D.I.:
Magneto model/manufacturer F5BT/YAMAHA
Pickup coil resistance (color) 656 ~ 984
Ω
at 20 °C (68 °F) (R–W)
Source coil resistance (color) 624 ~ 936
Ω
at 20 °C (68 °F) (Br–G)
C.D.I. unit-model/manufacturer 5LB/YAMAHA
Ignition coil:
Model/manufacturer 2JN/YAMAHA
Minimum spark gap 6 mm (0.24 IN) or more at 500 r/min
Primary winding resistance 0.18 ~ 0.28
Ω
at 20 °C (68 °F)
Secondary winding resistance 6.3 ~ 9.5 k
Ω
at 20 °C (68 °F)
Charging system:
Type A.C. magneto generator
Model/manufacturer 5FBT/YAMAHA
Charge coil resistance (color) 0.5 ~ 0.7
Ω
at 20 °C (68 °F) (W–W)
Rectifier/regulator:
Type Semi conductor type
Model/manufacturer SH629A-12/SHINDENGEN
No load regulated voltage 14.1 ~ 14.9 V
Capacity 10 A
Withstand voltage 200 V
Starter motor:
Model/manufacture 5FY/YAMAHA
Output 0.4 kW
Armature coil resistance 0.017 ~ 0.021
Ω
Brush overall length 10 mm (0.39 in)
<Limit> <3.5 mm (0.14 in)>
Brush spring pressure 560 ~ 840 g (19.8 ~ 29.6 oz)
<Limit> <450 g (0.98 oz)>
Commutator dia. 22 mm (0.87 in)
<Limit> <21 mm (0.83 in)>
Mica undercut 1.5 mm (0.06 in)
Flasher relay:
Type Full transistor
Model/manufacturer FE246BH/DENSO
Self cancelling device No.
Flasher frequency 75 ~ 95 cycle/min
Wattage 27 W
×
2 + 3.4 W
Circuit breaker:
Type Fuse
Amperage for individual circuit
Main 20 A
