– 5 –
SPEC
MAINTENANCE SPECIFICATIONS
Carburetor:
ID mark TW200EN: 5FY10
TW200ENC: 5FY00
Main jet (M.J.) TW200EN: #126
TW200ENC: #128
Main air jet (M.A.J.) 1.2
Jet needle-clip/position (J.N) TW200EN: 5B21-1/1
TW200ENC: 5B21-1/3
Main nozzle (M.N.) 2.600
Pilot jet (P.J.) #31
Pilot air jet (P.A.J.) TW200EN: 0.95
TW200ENC: 1.0
Pilot outlet 0.8
Bypass 0.7
Valve seat (V.S.) 1.6
Starter jet (G.S1.) 0.6
(G.S2.) 0.8
Fuel level
(above the line on the float chamber
mating surface) (F.L.)
0.5 ~ 1.5 mm (0.02 ~ 0.06 in)
Float height 10 ~ 11 mm (0.39 ~ 0.43 in)
Engine idling speed 1,300 ~ 1,500 r/min
Vacuum pressure at idling speed 29.3 ~ 34.7 kPa
(220 ~ 260 mmHg, 8.66 ~ 10.24 inHg) or more
Model TW200EN/TW200ENC
