DES-1228/ME Layer 2 Fast Ethernet Managed Switch
166
SuppTimeout
This value determines timeout conditions in the exchanges between the Authenticator and
the client. The default setting is 30 seconds.
ServerTimeout
This value determines timeout conditions in the exchanges between the Authenticator and
the authentication server. The default setting is 30 seconds.
MaxReq
The maximum number of times that the Switch will retransmit an EAP Request to the client
before it times out of the authentication sessions. The default setting is 2.
ReAuthPeriod
A constant that defines a nonzero number of seconds between periodic reauthentication of
the client. The default setting is 3600 seconds.
ReAuth
Determines whether regular reauthentication will take place on this port. The default setting
is Disabled.
Click Apply to implement configuration changes.
