DES-1228/ME Layer 2 Fast Ethernet Managed Switch
44
Log Settings
The Log settings can be changed by clicking the System Log Settings link to open the following window:
Figure 6- 17. Log Settings window
The following parameters can be set:
Parameter Description
Log Mode
Use this drop-down menu to choose the method that will trigger a log entry. You can choose
between On Demand, Log Trigger, and Time Interval.
Time Interval
Enter a time interval, in seconds, for which you would like a log entry to be made.
