![D-Link DES-1228/ME [231/267] Appendix b](/views2/1013273/page231/bge7.png)
DES-1228/ME Layer 2 Fast Ethernet Managed Switch
218
Appendix B
System Log Entries
The following table lists all possible entries and their corresponding meanings that will appear in the System Log of this Switch.
Category Event Description Log Content Severity
system System started up System started up Critical
Configuration saved to flash Configuration saved to flash
(Username: <username>, IP:
<ipaddr>, MAC: <macaddr>)
Informational
Configuration saved to flash by console Configuration saved to flash by
console (Username: <username>)
Informational
System log saved to flash System log saved to flash
(Username: <username>, IP:
<ipaddr>, MAC: <macaddr>)
Informational
System log saved to flash by console System log saved to flash by
console (Username: <username>)
Informational
Configuration and log saved to flash Configuration and log saved to
flash (Username: <username>, IP:
<ipaddr>, MAC: <macaddr>)
Informational
Configuration and log saved to flash by
console
Configuration and log saved to
flash by console (Username:
<username>)
Informational
Upload/Download Firmware upgraded successfully Firmware upgraded successfully
(Username: <username>, IP:
<ipaddr>)
Informational
Firmware upgraded by console
successfully
Firmware upgraded by console
successfully (Username:
<username>)
Informational
Firmware upgrade was unsuccessful Firmware upgrade was
unsuccessful! (Username:
<username>, IP: <ipaddr>)
Warning
Firmware upgrade by console was
unsuccessful
Firmware upgrade by console was
unsuccessful! (Username:
<username>)
Warning
Configuration successfully downloaded Configuration successfully
downloaded (Username:
<username>, IP: <ipaddr>)
Informational
Configuration successfully downloaded by
console
Configuration successfully
downloaded by console
(Username: <username>)
Informational
Configuration download was unsuccessful
Configuration download was
unsuccessful! (Username:
<username>, IP: <ipaddr>)
Warning
