DES-1228/ME Layer 2 Fast Ethernet Managed Switch
228
1.3.6.1.4.1.171.12.25.5.0.2
swPktStormOccurred
1.3.6.1.4.1.171.12.25.5.0.1
swPktStormCtrlPortIndex V2 PKT-STORM-CTRL-MIB
swSafeGuardChgToExhausted
1.3.6.1.4.1.171.12.19.4.1.0.1
swSafeGuardCurrentStatus V2 SAFEGUARD-ENGINE-MIB
swSafeGuardChgToNormal
1.3.6.1.4.1.171.12.19.4.1.0.2
swSafeGuardCurrentStatus V2 SAFEGUARD-ENGINE-MIB
swIpMacBindingViolationTrap
1.3.6.1.4.1.171.12.23.5.0.1
swIpMacBindingPorts
swIpMacBindingViolationIP
swIpMacBindingViolationMac
V2 IP-MAC-BIND-MIB
agentGratuitousARPTrap
1.3.6.1.4.1.171.12.1.7.2.0.5
agentGratuitousARPIpAddr
agentGratuitousARPMacAddr
agentGratuitousARPPortNumber
agentGratuitousARPInterfaceNa
me
V2 Genmgmt
(AGENT-GENERAL-MIB)
agentCfgOperCompleteTrap
1.3.6.1.4.1.171.12.1.7.2.0.9
unitID
agentCfgOperate
agentLoginUserName
V2 AGENT-GENERAL-MIB
swFilterDetectedTrap
1.3.6.1.4.1.171.12.37.100.0.1
swFilterDetectedIP
swFilterDetectedport
V2 FILTER-MIB
Proprietary Trap List (project dependent)
Trap Name/OID Variable Bind Format MIB Name
swL2macNotification
1.3.6.1.4.1.171.11.116.1.2.20.0.2
swL2macNotifyInfo V2 des1228ME-L2mgmt.mib
swL2PortSecurityViolationTrap
1.3.6.1.4.1.171.11.116.1.2.20.0.1
swL2PortSecurityPortIndex
swL2PortSecurityViolationMac
V2 des1228ME-L2mgmt.mib
swL2FloodMacDetectedTrap
1.3.6.1.4.1.171.11.116.1.2.20.0.3
swL2FloodMacDetectedMacVid
swL2FloodMacDetectedMacAddr
ess
V2 des1228ME-L2mgmt.mib
