DES-1228/ME Layer 2 Fast Ethernet Managed Switch
107
The following parameters can be set or displayed:
Parameter Description
From/To
Select a port or group of ports using the pull-down menus.
Port VLAN ID Use the drop-down menu to toggle Port VLAN ID between Enabled and Disabled.
VLAN Name Use the drop-down menu to toggle among VLAN ID, VLAN Name, and All. Use the drop-
down menu to toggle between Enabled and Disabled.
Protocol Identity Use the drop-down menu to toggle among EAPOL, LACP, GVRP, STP, and All. Use the
drop-down menu to toggle between Enabled and Disabled.
Click Apply to implement changes made.
802.3 Extension LLDP Port Settings
The following window is used to set up 802.3 extension LLDP on individual port(s) on the Switch. To view this window click L2
Features > LLDP > 802.3 Extension LLDP Port Settings.
