DES-1228/ME Layer 2 Fast Ethernet Managed Switch
227
Flooding MAC
Detection
Flooding MAC is detected The flooding MAC is detected
(VID : <vlanID>, MAC:
<macaddr>)
Information
DHCP
Detect untrusted DHCP server IP address Detected untrusted DHCP server
(IP: <ipaddr>, Port: <portNum>)
Information
Standard Trap List
Trap Name/OID Variable Bind Format MIB Name
risingAlarm
1.3.6.1.2.1.16.0.1
alarmIndex
alarmVariable
alarmSampleType
alarmValue
alarmRisingThreshold
V2 rfc2819
(RMON-MIB)
fallingAlarm
1.3.6.1.2.1.16.0.2
alarmIndex
alarmVariable
alarmSampleType
alarmValue
alarmFallingThreshold
V2 rfc2819
(RMON-MIB)
LldpRemTablesChange
1.0.8802.1.1.2.0.0.1
lldpStatsRemTablesInserts
lldpStatsRemTablesDeletes
lldpStatsRemTablesDrops
lldpStatsRemTablesAgeouts
V2 LLDP-MIB
coldStart
1.3.6.1.6.3.1.1.5.1
None V2 rfc1907
(SNMPv2-MIB)
warmStart
1.3.6.1.6.3.1.1.5.2
None V2 rfc1907
(SNMPv2-MIB)
authenticationFailure
1.3.6.1.6.3.1.1.5.5
None V2 rfc1907
(SNMPv2-MIB)
linkDown
1.3.6.1.6.3.1.1.5.3
ifIndex
ifAdminStatus
ifOperStatus
V2 rfc2863
(IF-MIB)
linkUp
1.3.6.1.6.3.1.1.5.4
ifIndex
ifAdminStatus
ifOperStatus
V2 rfc2863
(IF-MIB)
newRoot
1.3.6.1.2.1.17.0.1
None V2 rfc1493
(BRIDGE-MIB)
topologyChange
1.3.6.1.2.1.17.0.2
None V2 rfc1493
(BRIDGE-MIB)
Proprietary Trap List
Trap Name/OID Variable Bind Format MIB Name
swPktStormCleared swPktStormCtrlPortIndex V2 PKT-STORM-CTRL-MIB
