DES-1228/ME Layer 2 Fast Ethernet Managed Switch
226
IP-Mac-port Binding Unauthentiucated IP address discarded
by IP mac port binding
Unathenticated IP-MAC address
and discarded by ip mac port
binding (IP: <ipaddr>, MAC
<macaddr>, Port <portNum>)
Warning
Gratuitous ARP Conflict IP was detected with this device Conflict IP was detected with this
device (IP: <ipaddr>, MAC:
<macaddr>, Port <portNum>),
Interface: <interface>)
Informational
802.1X
Radius server assigned VID: to port Radius server r<server_ip>
assigned VID: <VLAN_ID> to Port
<portNum> (Account:
<user_account>)
Informational
Radius server assigned ingress bandwith:
Kbits to port
Radius server r<server_ip>
assigned ingress bandwith:
<bandwidth_value>Kbits to
Port<portNum> (Account:
<user_account>)
Informational
Radius server assigned ingress bandwith:
no limit to port
Radius server r<server_ip>
assigned ingress bandwith: no limit
to Port <portNum> (Account:
<user_account>)
Informational
Radius server assigned egress
bandwidth: Kbits to port
Radius server<server_ip>
assigned egress bandwidth:
<bandwidth_value> Kbits to Port
<portNum> (Account:
<user_account>)
Informational
Radius server assigned egress bandwith
no limit to Port
Radius server <server_ip>
assigned egress bandwith: no limit
to Port<portNum> (Account:
<user_account>)
Informational
Radius server assigned 802.1p default
priority: to Port
Radius serverr<server_ip>
assigned 802.1p default priority:
<portNum> to Port <portNum>
(Account: <user_account>)
Informational
802.1x Authentication failure 802.1x Authentication failure from
(Username: <user_account>, Port
<portNum>, MAC: <macaddr>)
Warning
802.1x Authentication failure for the radius
server
802.1x Authentication failure for
the radius server <server_ip>
timeout from (Username:
<user_account>, Port <portNum>,
MAC: <macaddr>)
Warning
802.1x Authentication failure for the
802.1X client session timeout
802.1x Authentication failure for
the 802.1X client session timeout
from (Username: <user_account>,
Port <portNum>, MAC:
<macaddr>)
Warning
802.1x Authentication success 802.1x Authentication success
from (Username: <user_account>,
Port <portNum>, MAC:
<macaddr>)
Informational
Loopback Detection
Port Loop occurred Configuration Testing Protocol
detects a loop in port <portNum>
Informational
