DES-1228/ME Layer 2 Fast Ethernet Managed Switch
225
Successful Enable Admin through SSH
authenticated by AAA server
Successful Enable Admin through
SSH from <userIP> authenticated
by AAA server <serverIP>
(Username: <username>)
Informational
Enable Admin failed through SSH
authenticated by AAA server
Enable Admin failed through SSH
from <userIP> authenticated by
AAA server <serverIP>
(Username: <username>)
Warning
Enable Admin failed through SSH due to
AAA server timeout or improper
configuration
Enable Admin failed through SSH
from <userIP> due to AAA server
timeout or improper configuration
(Username: <username>)
Warning
AAA server response is wrong AAA server <serverIP> (Protocol:
<protocolname>) response is
wrong
Warning
AAA doesn't support this functionality. AAA doesn't support this
functionality.
Warning
AAA server connection failed AAA server <serverIP> (Protocol:
<protocolname>) connection failed
Warning
Port security Port security has exceeded its maximum
learning size and will not learn any new
addresses
Port security violation (MAC:
<macaddr>, Port: <portNum>)
Warning
IP and Password
Changed
IP Address change activity Management IP address was
changed by (Username:
<username>,
IP:<ipaddr>,MAC:<macaddr>)
Informational
Password change activity Password was changed by
(Username: <username>,
IP:<ipaddr>,MAC:<macaddr>)
Informational
Safeguard Engine Safeguard Engine is in normal mode Safeguard Engine enters
NORMAL mode
Informational
Safeguard Engine is in exhausted mode Safeguard Engine enters
EXHAUSTED mode
Warning
Packet Storm Broadcast strom occurrence Port <portNum> Broadcast storm
is occurring
Warning
Broadcast storm cleared Port <portNum> Broadcast storm
has cleared
Informational
Multicast storm occurrence Port <portNum> Multicast storm is
occurring
Warning
Multicast storm cleared Port <portNum> Multicast storm
has cleared
Informational
Port shutdown due to a packet storm Port <portNum> is currently
shutdown due to a packet storm
Warning
