DES-1228/ME Layer 2 Fast Ethernet Managed Switch
224
Successful Enable Admin through Telnet
authenticated by AAA none method
Successful Enable Admin through
Telnet from <userIP>
authenticated by AAA none
method (Username: <username>)
Informational
Successful Enable Admin through SSH
authenticated by AAA none method
Successful Enable Admin through
SSH from <userIP> authenticated
by AAA none method (Username:
<username>)
Informational
Successful Enable Admin through
Console authenticated by AAA server
Successful Enable Admin through
Console authenticated by AAA
server <serverIP> (Username:
<username>)
Informational
Enable Admin failed through Console
authenticated by AAA server
Enable Admin failed through
Console authenticated by AAA
server <serverIP> (Username:
<username>)
Warning
Enable Admin failed through Console due
to AAA server timeout or improper
configuration
Enable Admin failed through
Console due to AAA server
timeout or improper configuration
(Username: <username>)
Warning
Successful Enable Admin through Web
authenticated by AAA server
Successful Enable Admin through
Web from <userIP> authenticated
by AAA server <serverIP>
(Username: <username>)
Informational
Enable Admin failed through Web
authenticated by AAA server
Enable Admin failed through Web
from <userIP> authenticated by
AAA server <serverIP>
(Username: <username>)
Warning
Enable Admin failed through Web due to
AAA server timeout or improper
configuration
Enable Admin failed through Web
from <userIP> due to AAA server
timeout or improper configuration
(Username: <username>)
Warning
Successful Enable Admin through Telnet
authenticated by AAA server
Successful Enable Admin through
Telnet from <userIP>
authenticated by AAA server
<serverIP> (Username:
<username>)
Informational
Enable Admin failed through Telnet
authenticated by AAA server
Enable Admin failed through
Telnet from <userIP>
authenticated by AAA server
<serverIP> (Username:
<username>)
Warning
Enable Admin failed through Telnet due
to AAA server timeout or improper
configuration
Enable Admin failed through
Telnet from <userIP> due to AAA
server timeout or improper
configuration (Username:
<username>)
Warning
