DES-1228/ME Layer 2 Fast Ethernet Managed Switch
217
Combo ports in the front panel
combo 1000BASE-T/SFP ports
1000BASE-T ports compliant to following standards:
2 IEEE 802.3 compliance
3 IEEE 802.3u compliance
4 IEEE 802.3ab compliance
5 Support Full-Duplex operations
6 IEEE 802.3x Flow Control support for Full-Duplex mode
, back pressure
when Half-Duplex mode, and Head-of-line blocking prevention
SFP Transceivers Supported:
− DEM-310GT (1000BASE-LX)
− DEM-311GT (1000BASE-SX)
− DEM-314GT (1000BASE-LH)
− DEM-315GT (1000BASE-ZX)
− DEM-210 (Single Mode 100BASE-FX)
− DEM-211 (Multi Mode 100BASE-FX)
WDM Transceiver Supported:
1.DEM-330T (TX-1550/RX-1310nm),up to 10km,Single-Mode
2.DEM-330R (TX-1310/RX-1550nm), up to 10km,Single-Mode
3.DEM-331T (TX-1550/RX-1310nm), up to 40km, Single-Mode
4.DEM-331R (TX-1310/RX-1550nm), up to 40km, Single-Mode
Compliant to following standards:
6-1 IEEE 802.3z compliance
6-2 IEEE 802.3u compliance
1000BASE-T ports in the front panel
1000BASE-T ports compliant to following standards:
1. IEEE 802.3 compliance
2. IEEE 802.3u compliance
3. IEEE 802.3ab compliance
4. Support Full-Duplex operations
5. IEEE 802.3x Flow Control support for Full-Duplex mode
, back pressure
when Half-Duplex mode, and Head-of-line blocking prevention
