DES-1228/ME Layer 2 Fast Ethernet Managed Switch
219
Configuration download by console was
unsuccessful
Configuration download by
console was unsuccessful!
(Username: <username>)
Warning
Configuration successfully uploaded Configuration successfully
uploaded (Username:
<username>, IP: <ipaddr>)
Informational
Configuration successfully uploaded by
console
Configuration successfully
uploaded by console (Username:
<username>)
Configuration upload was unsuccessful Configuration upload was
unsuccessful! (Username:
<username>, IP: <ipaddr>)
Warning
Configuration upload by console was
unsuccessful
Configuration upload by console
was unsuccessful! (Username:
<username>)
Warning
Log message successfully uploaded Log message successfully
uploaded (Username:
<username>, IP: <ipaddr>)
Informational
Log message successfully uploaded by
console
Log message successfully
uploaded by console (Username:
<username>)
Informational
Log message upload was unsuccessful Log message upload was
unsuccessful! (Username:
<username>, IP: <ipaddr>)
Warning
Log message upload by console was
unsuccessful
Log message upload by console
was unsuccessful! (Username:
<username>)
Warning
Interface Port link up Port <portNum> link up, <link
state>
Informational
Port link down Port <portNum> link down Informational
Console Successful login through Console Successful login through Console
(Username: <username>)
Informational
Login failed through Console Login failed through Console
(Username: <username>)
Warning
Logout through Console Logout through Console
(Username: <username>)
Informational
Console session timed out Console session timed out
(Username: <username>)
Informational
Web Successful login through Web Successful login through Web
(Username: <username>, IP:
<ipaddr>)
Informational
Login failed through Web Login failed through Web
(Username: <username>, IP:
<ipaddr>)
Warning
