DES-1228/ME Layer 2 Fast Ethernet Managed Switch
220
Logout through Web Logout through Web (Username:
<username>, IP: <ipaddr>)
Informational
Telnet Successful login through Telnet Successful login through Telnet
(Username: <username>, IP:
<ipaddr>)
Informational
Login failed through Telnet Login failed through Telnet
(Username: <username>, IP:
<ipaddr>)
Warning
Logout through Telnet Logout through Telnet (Username:
<username>, IP: <ipaddr>)
Informational
Telnet session timed out Telnet session timed out
(Username: <username>, IP:
<ipaddr>)
Informational
SNMP SNMP request received with invalid
community string
SNMP request received from
<ipAddress> with invalid
community string!
Informational
STP Topology changed Topology changed
(Instance:<InstanceID>
port<portNum>)
Informational
New Root selected [CIST | MSTI] New Root selected
(Instance: <InstanceID> Root
bridge MAC: <macaddr> Priority:
<value>)
Informational
BPDU Loop Back on port BPDU Loop Back on Port
<portNum>
Warning
Spanning Tree Protocol is enabled Spanning Tree Protocol is enabled Informational
Spanning Tree Protocol is disabled Spanning Tree Protocol is disabled
Informational
SSH Successful login through SSH Successful login through SSH
(Username: <username>, IP:
<ipaddr>)
Informational
Login failed through SSH Login failed through SSH
(Username: <username>, IP:
<ipaddr>)
Warning
Logout through SSH Logout through SSH (Username:
<username>, IP: <ipaddr>)
Informational
SSH session timed out SSH session timed out
(Username: <username>, IP:
<ipaddr>)
Informational
SSH server is enabled SSH server is enabled Informational
SSH server is disabled SSH server is disabled Informational
AAA Authentication Policy is enabled Authentication Policy is enabled
(Module: AAA)
Informational
Authentication Policy is disabled Authentication Policy is disabled Informational
