DES-1228/ME Layer 2 Fast Ethernet Managed Switch
201
The following fields can be viewed or set:
Parameter Description
VLAN Name
Enter a VLAN Name by which to browse the forwarding table.
MAC Address
Enter a MAC address by which to browse the forwarding table.
Port
Select the port by using the corresponding pull-down menu.
Find
Allows the user to move to a sector of the database corresponding to a user defined port,
VLAN, or MAC address.
VID
The VLAN ID of the VLAN of which the MAC address above corresponds.
MAC Address
The MAC address entered into the address table.
Port
The port to which the MAC address corresponds.
Type
Describes the method which the Switch discovered the MAC address. The possible entries
are Dynamic, Self, DeleteOnReset and Permanent.
Next
Click this button to view the next page of the address table.
View All Entry
Clicking this button will allow the user to view all entries of the address table.
Add to Static MAC-
address Table
This function will add the entry to the Static MAC-address table and change its Type to
Permanent.
