DES-1228/ME Layer 2 Fast Ethernet Managed Switch
222
Successful login through SSH
authenticated by AAA none method
Successful login through SSH from
<userIP> authenticated by AAA
none method (Username:
<username>)
Informational
Successful login through Console
authenticated by AAA server
Successful login through Console
authenticated by AAA server
<serverIP> (Username:
<username>)
Informational
Login failed through Console
authenticated by AAA server
Login failed through Console
authenticated by AAA server
<serverIP> (Username:
<username>)
Warning
Login failed through Console due to AAA
server timeout or improper configuration
Login failed through Console due
to AAA server timeout or improper
configuration
(Username:<username>)
Warning
Successful login through Web
authenticated by AAA server
Successful login through Web from
<userIP> authenticated by AAA
server <serverIP> (Username:
<username>)
Informational
Login failed through Web authenticated by
AAA server
Login failed through Web from
<userIP> authenticated by AAA
server <serverIP> (Username:
<username>)
Warning
Login failed through Web due to AAA
server timeout or improper configuration
Login failed through Web from
<userIP> due to AAA server
timeout or improper configuration
(Username:<username>)
Warning
Successful login through Telnet
authenticated by AAA server
Successful login through Telnet
from <userIP> authenticated by
AAA server <serverIP>
(Username: <username>)
Informational
Login failed through Telnet authenticated
by AAA server
Login failed through Telnet from
<userIP> authenticated by AAA
server <serverIP> (Username:
<username>)
Warning
Login failed through Telnet due to AAA
server timeout or improper configuration
Login failed through Telnet from
<userIP> due to AAA server
timeout or improper configuration
(Username: <username>)
Warning
Successful login through SSH
authenticated by AAA server
Successful login through SSH from
<userIP> authenticated by AAA
server <serverIP> (Username:
<username>)
Informational
Login failed through SSH authenticated by
AAA server
Login failed through SSH from
<userIP> authenticated by AAA
server <serverIP> (Username:
<username>)
Warning
Login failed through SSH due to AAA Login failed through SSH from
<userIP> due to AAA server
Warning
