DES-1228/ME Layer 2 Fast Ethernet Managed Switch
63
Address
address.
Port Settings
Allows the selection of ports that will be members of the static multicast group. The options
are:
None - When None is chosen, the port will not be a member of the Static Multicast Group.
Egress - The port is a static member of the multicast group.
Click Apply to implement the changes made. To delete an entry in the Static Multicast Forwarding Table, click the corresponding
X under the Delete heading. Click the Show All Multicast Forwarding Entries
link to return to the Static Multicast Forwarding
Settings window.
