DES-1228/ME Layer 2 Fast Ethernet Managed Switch
67
Figure 6-46. SMTP Service window
The following parameters can be set:
Parameter Description
Subject
Enter the subject of the test e-mail.
Content
Enter the content of the test e-mail.
Once your message is ready, click Send to send this mail to all recipients configured on the Switch for SMTP.
