Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 44 Plastic Tube Guide 2

2 Main Frame 1 46 Swing Tube Scaleboard 1

3 Rear Cross Brace 1 47 Top Plate 1

4 Bottom Cross Brace 1 48 Grip Φ30*Φ22*180 2

5 Swing Tube 1 49 Selector Pin W/Coil 1

6 Adj. Handle 1 51 Button 10

7 Pivot Arm 1 53 Weight Rubber Bumper 2

8 Back Pad Support 1 54 Adjustable Foot plate 4

9 Handle 1 55 Adjustable Support 1

10 Cam 1 59 Bearing Φ50.8*Φ25.4*15.9 6

11 Main Bracket 1 60 Adjustable Support Sleeve 1

12 Scaleboard 1 61 Yellow Grip 1

13 Cable 1 62 Seat Pad Plate 1

15 Main Shaft 1 63 Little Bumper 4

16 Adjustable tube 1 64 Bushing 2

17 Flange 2 65 Plate 2

18 Pin 1 68 Front Shroud 1

20 Cap 3 69 Rear Shroud 1

26 Guide Rod 2 70 Pin End 1

27 4.5" Pulley 2 71 Pin Pole 1

29 Back Pad 1 72 Ball 1

32 Seat Pad 1 73 Spring Φ1.2*Φ13*38.6 1

33 Roller 1 75 Nut 2

34 Plug RT50*100 6 76 Hex Head Bolt M12*35 4

35 Counter Poise Block 1 77 Socket Head Cap Screw M4*15 1

36 Aluminium Grip Cap 2 79 Hex Head Bolt M10*100 2

37 Aluminium Grip Ring 2 80 Hex Head Bolt M10*80 4

38 Big Collar 2 81 Rivet Nut M8 2

39 Collar 1 82

Button Head Cap Screw M10*65

40 Bumper 1 83 Hex Head Bolt M10*55 3
