Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

62 Hex Head Bolt M10*50 2 90 Flat Head Cap Screw M10*30 2

63 Hex Head Bolt M10*30 8 91 Hex Key S=3/16" 1

64 Hex Head Bolt M8*30 2 92 Rivet Nut M8 2

65 Button Head Cap Screw M10*65 4 93 Spring Washer Φ8 2

66 Button Head Cap Screw M10*25 2 97 Left Plug 1

67 Button Head Cap Screw M8*55 1 98 Right Plug 1

68 Button Head Cap Screw M6*12 4 100 Front Shroud 1

69 Socket Head Cap Screw M10*50 5 101 Rear Shroud 1

70 Socket Head Cap Screw M8*30 1 102 Top Shroud 1

71 Flat Head Cap Screw M10*25 8 115 Flat Head Cap Screw M6*15 2

74 Socket Set Screw 10-32*3.2 4 116 Hex Key S=3 1

75 Flat Washer Φ13*Φ24*1.5 4 117 Philips Screw M5*12 9

76 Flat Washer Φ11*Φ20*2 47 118 Rivet Nut M5 5

77 Flat Washer Φ9*Φ16*1.6 2 119 Hex Head Bolt M10*75 2

78 Flat Washer Φ9*Φ22*1.6 2 120 Shroud Clip 12

79 Nylon lock Nut M12 4 121 Plastic Cover 1

80 Nylon lock Nut M10 22 122 4.5" Pulley for Sensor 1

81 Nylon lock Nut M8 2 123 Plate for Sensor 1

82 Hex Nut M6 4 124 Philips Screw M3*8 4

83 Hex Key S=4 1 125 Sensor 2

84 Hex Key S=5 1 126 Console PCB 1

85 Hex Key S=6 1 127 Cover for Magnetic Iron 1

86 Hex Key S=8 1 128 Magnetic Iron 2

87 Hex Key S=3/32" 1 129 Screw ST2.9*9.5 2

88 Wrench 1 130 Hex Head Bolt M10*55 1

89 Lube 1
