Assembly

1. Attach four Adj. Foot Plate (#30) to the Main Frame (#2) and the Weight Stack

Frame (#1).

2. Attach the Bottom Cross Brace (#8) to the Weight Stack Frame (#1), Using:

● two M10*100 HHB (#76)

● four Φ11*Φ20*2 Flat Washers (#96)

● two M10 Nylon Lock Nuts (#99)

3. Attach the Bottom Cross Brace (#8) to the Main Frame (#2), Using:

● two M10*135 HHB (#74)

● four Φ11*Φ20*2 Flat Washers (#96)

● two M10 Nylon Lock Nuts (#99)

4. Attach the Rear Cross Brace (#9) to the Weight Stack Frame (#1), Using:

● two M10*75 HHB (#75)

● four Φ11*Φ20*2 Flat Washers (#96)

● two M10 Nylon Lock Nuts (#99)

5. Attach the Rear Cross Brace (#9) to the Main Frame (#2), Using:

● two M10*135 HHB (#74)

● four Φ11*Φ20*2 Flat Washers (#96)

● two M10 Nylon Lock Nuts (#99)

Note: Hand tighten Bolts and Nylon Lock nuts.

STEP 2

1. Attach the Cam (#3) to Main Frame (#2).

2. Attach the Swivel Frame (#4) to the Cam (#3), Using:

● one Φ37*Φ30.5*15 Adjust Spacer (#13)

3. Attach the Angle Support (#5) to Main Frame (#2), Using:

● one Φ37*Φ30.5*15 Adjust Spacer (#13)

● two M10*80 HHB (#77)

● three Φ11*Φ20*2 Flat Washers (#96)

● one M10 Nylon Lock Nut (#99)

● one M10*30 HHB (#81)

● one Φ38*Φ11*5 Big Washer (#139)

● one Φ10 Spring Washer (#140)

4. Attach the Support of Chest Pad (#6) to the Main Frame (#2), Using:

● two M10*35 HHB (#80)

● four Φ11*Φ20*2 Flat Washers (#96)

● two M10 Nylon Lock Nuts (#99)

Note: Wrench Tighten bolts and Nylon Lock nuts.

STEP 1
