─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

1 Weight Stack Frame 1 36 Seat Pad 1

2 main frame 1 37 Arm Pad 4

3 Cam 1 39 Rear Shroud 1

4 Swivel Frame 1 43 Top Front Shroud 1

5 Angle Support 1 45 Front Shroud 1

6 Support of Chest Pad 1 47 Button 8

7 Cross Brace 1 50 4.5" Pulley Cover 4

8 Bottom Cross Brace 1 52 Plastic Tube Guide 2

9 Rear Cross Brace 1 53 Plug RT50*100 1

10 Seat Pad Support 1 54 Φ25 Aluminium Grip Cap 4

11 Joy Stick 1 55 Φ25 Aluminium Grip Ring 4

12 Pin 1 57 Taper Head 1

13 Adjust Spacer 2 58 Adjustable Support Sleeve 1

14 Drive Support 1 59 Weight Rubber Bumper 2

15 Slip Rod 2 60 Foot Sleeve 2

16 Backstop 1 61 Rubber sleeve 3

17 Wheel of Rotation 1 62 Bushing 1

18 Axis of Rotation 1 63 4.5" Pulley 4

19 Scaleboard 1 64 3.5" Pulley 2

20 Grip Φ30*Φ22*270 2 65 Bearing 6006-2Z 2

21 Grip Φ30*Φ22*180 2 66 Taper Bearig 30206 2

22 Guide Rod 2 67 0.75" Bearing Φ35*Φ19.1*13.5 2

23 Cable 1 1 68 Linear Bearing Φ25 3

24 Cable 2 1 69 Spring 1

25 Rod 1 72 Foot Plate 2

26 Pulley bracket 1 73 Grease Cap 1

27 Adjustable Support 1 74 Hex Head Bolt M10*135 4

28 Plate 2 75 Hex Head Bolt M10*75 2

29 Bearing Washer 2 76 Hex Head Bolt M10*100 2

30 Adj. Foot Plate 4 77 Hex Head Bolt M10*80 2

31 Selector Pin W/Coil 1 78 Hex Head Bolt M10*70 1

32 Top Plate 1 79 Hex Head Bolt M10*50 2
