─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED.

ITEM NO.

Description QTY

ITEM NO.

Description QTY

80 Hex Head Bolt M10*35 2 113 Spacer 1

81 Hex Head Bolt M10*30 11 114 Hole Clip 3

82 Button Head Cap Screw M8*30 2 116 Hex Key S=3/16" 1

83 Button Head Cap Screw M8*55 1 117 Hex Flanged Nut 1/2"-13 1

84 Hex Head Bolt M8*12 8 118 Cable Connector Φ20*77*1/2"-13 1

85 Button Head Cap Screw M6*12 2 119 Hex Key S=4 1

86 Socket Head Cap Screw M12*30 2 121 Rivet Nut M8 2

87 Socket Head Cap Screw M10*50 3 122 Rubber Plug Φ29*Φ19*10 2

88 Socket Head Cap Screw M8*30 1 123 Spring Washer Φ8 2

89 Socket Head Cap Screw M8*20 5 133 Hex Head Bolt M8*30 2

90 Socket Head Cap Screw M5*20 2 134 Weight Stack Space 2

91 Socket Head Cap Screw M5*10 8 137 Socket Set Screw M6*15 2

92 Flat Head Cap Screw M10*30 4 138 Hex Key S=3 1

93 Flat Washer Φ9*Φ22*1.6 2 139 Flat Washer Φ38*Φ11*5 1

94 Nut 4 140 Spring washer Φ10 1

95 Flat Washer Φ13*Φ24*2.5 4 145 4.5" Pulley for Sensor 1

96 Flat Washer Φ11*Φ20*2 43 146 Cover for Magnetic Iron 1

97 Flat Washer Φ9*Φ16*1.6 17 147 Magnetic Iron 4

98 Flat Washer Φ5.5*Φ10*1 4 148 Screw ST2.9*9.5 2

99 Nylon Lock Nut M10 18 149 Hex Head Bolt M10*55 1

100 Nylon Lock Nut M8 8 150 Screw M5*12 9

101 Nylon Lock Nut M5 2 151 Rivet Nut M5 5

102 Hex Nut M10 1 152 Shroud clip 12

103 Hex Nut M6 2 153 Plastic Cover 1

104 Socket Set Screw 10-32*3.2 8 154 Plate for sensor 1

106 Hex Key S=5 1 155 Philips Screw M3*8 4

107 Hex Key S=6 1 156 Sensor 2

108 Hex Key S=8 1 157 Console PCB 1

109 Hex Key S=3/32" 1 160 Support 1

110 Wrench Φ6*117 1 161 Top Shroud 1

111 Lube 1 162 Left Plug 1

112 Socket Head Cap Screw M12*95 2 163 Right Plug 1
