─ 15 ─

Assembly

1. Attach the Cable 1 (#23) to Top Plate (#32) and Weight Stack Frame (#1).

2. Attach the Cable 1 (#23) to the Weight Stack Frame (#1) and Top Plate (#32)

through two 3.5” Pulley (#64) and One 4.5" Pulley for Sensor (#145).

3. Attach the Cable 2 (#24) to the Cross Brace (#7).

4. Attach one 4.5" Pulley (#63) to the Main Frame (#2), Using:

● one 4.5" Pulley Cover (#50)

● one M10*50 SHCS (#87)

● one Φ11*Φ20*2 Flat Washer (#96)

● one M10 Nylon Lock Nut (#99)

. Attach one 4.5" Pulley (#63) to the Cross Brace (#8), Using:

● one 4.5" Pulley Cover (#50)

● one M10*50 SHCS (#87)

● one Φ11*Φ20*2 Flat Washer (#96)

● one M10 Nylon Lock Nut (#99)

. Attach one 4.5" Pulley (#63) to the Weight Stack Frame (#1), Using:

● two 4.5" Pulley Covers (#50)

● one M10*50 SHCS (#87)

● one M10 Nylon Lock Nut (#99)

. Attach the Cable2 (#24) to the Pulley bracket (#26), using:

● one 1/2"-13 Hex Flanged Nut (#117)

● one Φ20*77*1/2"-13 Cable Connector (#118)

Note: Wrench Tighten Bolts and Nylon Lock nuts.

STEP 4
