Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

1 Weight Stack Frame 1 32 Seat Pad 1

2 Main Frame 1 33 Roller 1

3 Rear Cross Brace 1 34 Plug RT50*100 6

4 Bottom Cross Brace 1 35 Counter Poise Block 1

5 Swing Tube 1 36 Aluminium Grip Cap 2

6 Adj. Handle 1 37 Aluminium Grip Ring 2

7 Pivot Arm 1 38 Big Collar 2

8 Back Pad Support 1 39 Collar 1

9 Handle 1 40 Bumper 1

10 Cam 1 44 Plastic Tube Guide 2

11 Main Bracket 1 46 Swing Tube Scaleboard 1

12 Scaleboard 1 47 Top Plate 1

13 Cable 1 48 Grip Φ30*Φ22*180 2

14 Shroud Retainer Plate 4 49 Selector Pin W/Coil 1

15 Main Shaft 1 50 Support 1

16 Adjustable Tube 1 51 Button 19

17 Flange 2 53 Weight Rubber Bumper 2

18 Pin 1 54 Adjustable Foot plate 4

19 L Bracket 4 55 Adjustable Support 1

20 Cap 3 56 Plastic Washer 4

21 Plastic Block 11 57 Plastic Cover 4

22 Upper Side Cover 1 59 Bearing Φ50.8*Φ25.4*15.9 6

23 Lower Side Cover 1 60 Adjustable Support Sleeve 1

24 Side Cover 1 61 Yellow Grip 1

25 PlugΦ95.4*61 2 62 Seat Pad Plate 1

26 Guide Rod 2 63 Little Bumper 4

27 4.5" Pulley 3 64 Bushing 2

29 Back Pad 1 65 Plate 2

30 Top Rear Shroud A 1 66 Plug 4

31 Top Front Shroud 1 67 Connect Button 4
