─ 18 ─

AssemblyAssembly

STEP 7

1. Attach the Front Shroud (#100) and the Rear Shroud (#101) to the Weight

Stack Frame (#1) using:

eight Φ8*Φ20*23 Buttons (#43)

2. Attach the Top Front Shroud (#47) and the Support (#48) to the Weight Stack

Frame (#1) using:

three M5*16 Flat Philips Screw (#72)

3. Attach the Top Rear Shroud-A (#97) and the Rear Support (#102) to the

Weight Stack Frame (#1) using:

three Φ8*Φ20*23 Buttons (#43) two M5*25 Flat Philips Screw (#95)

Note: Wrench Tighten Βolts and Nylon Lock nuts.

Here is the assembly instruction for Long Shroud !
