─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

1 Weight Stack Frame 1 28 Pulley Cover Φ140*26 9

2 Main Fram 1 29 Plug RT50*100 2

3 Front Sway Frame 1 30 Aluminum End Cap Φ50*Φ10.5*8 8

4 Back Sway Frame 1 31 Aluminium Grip Cap 2

5 Connect Frame 1 32 Aluminium Grip ring 2

6 Handle 1 33 Nut 25*2.5*21.6 2

7 Adjustable Tube 1 34 Hex Flanged Nut 1/2"-13 1

8 Bottom Cross Brace 1 35 Bearing Φ50.8*Φ25.4*15.9 8

9 Rear Cross Brace 1 36 Adjustable End Φ21*90 1

10 Footplate 1 37 Bolt Φ9.4*47.5*M8 1

11 Pivot Axle Φ25.4*222 2 38 Cable Connector Φ20*77*1/2"-13 1

12 Pivot Axle Φ25.4*332 2 39 Bronze Bushing Φ12.7*Φ9.5*9.5 2

13 Rubber Foot Plate Cover 1 40 Plug 2

14 Back Pad Support 1 41 Split Pin Φ11*76 1

15 Adjustable Foot Plate 4 42

Plug □30*70

16 Adjustable Support 1 43 Button Φ8*Φ20*23 19

17 Seat Pad 1 44 Plug Φ95.4*61 2

18 Back Pad 1 45 Side Cover 2

19 Top Plate 1 46 Top Rear Shroud 1

20 Selector Pin W/Coil 1 47 Top Front Shroud 1

21 Cable 1 48 Support 1

22 4.5" Pulley 8 49 Plastic Block 12

Weight Rubber Bumper Φ63.5*Φ19*25.4

2 50 Short Shroud Retainer Plate 2

24 Rubber Washer 2 51 Shroud 1

25 Spring Φ1.2*Φ13*38.6 1 52 Rubber Plug Φ29*Φ19*10 2

26 Grip STΦ30*Φ22*180 2 53 Little Plastic Tube Guide 2

27 Guide Rod Φ19*1177 2 54 Plastic Tube Guide 2
