─ 10 ─
Assembly
STEP 1
1. Attach two Adjustable Foot plate (#25) to the Weight Stack Frame (#1).
2. Attach three Shroud Retainer Plate (#108) and one Right Short Shroud
Retainer Plate (#120) to the Weight Stack Frame (#1), using:
twelve M5*16 Flat Philips Screws (#77)
Note: Wrench Tighten Screws.
Here is the assembly instruction for Long Shroud !
