─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

60 Connect Button Φ18*12 4 90 Hex Key s=5 1

61 Short Shroud Retainer Plate 2 91 Hex Key s=6 1

62 Hex Head Bolt M10*135 4 92 Hex Key s=8 1

63 Hex Head Bolt M8*30 2 93 Hex Key s=12 1

64 Hex Head Bolt M10*100 2 94 Hex Key s=3/32" 1

65 Hex Head Bolt M10*50 2 95 Wrench 1

66 Hex Head Bolt M10*30 8 96 Lube 1

67 Hex Head Bolt M10*25 4 98 Tie Rod End (Left) M16*Φ16 2

68 Button Head Cap Screw M8*55 1 99 Hex Nut (Left) M16 2

69 Hex Head Bolt M10*45 1 101 Hex Key s=4 1

70 Hex Head Bolt M12*40 2 102 Hex Head Bolt M10*80 2

71 Socket Head Cap Screw M10*50 5 103 Aluminium Cap Φ38*Φ10.5*8 2

72 Socket Head Cap Screw M8*30 1 104 Flat Head Cap Screw M10*25 9

73 Socket Head Cap Screw M16*40 4 105 Aluminium Grip Cap 2

74 Button Head Cap Screw M6*12 2 106 Cable End 1

75 Hex Head Bolt M10*20 2 107 Spacer Φ10*Φ14*20 1

76 Flat Head Cap Screw M10*30 4 108 Shroud Retainer Plate 3

77 Flat Philips Screw M5*16 17 109 Nut 2

78 Self-Tapping Screw ST4.2*10 4 110 Cushion 1

79 Flat Washer Φ13*Φ24*1.5 2 111 Top Rear Shroud-A 1

80 Flat Washer Φ11*Φ20*2 39 112 Rear Support 1

81 Flat Washer Φ9*Φ16*1.6 2 113 Flat Philips Screw M5*25 2

82 Hex Nut M6 2 114 Tapped Hole Nut M8 2

83 Hex Nut M16 2 115 Rubber Plug Φ29*Φ19*10 2

84 Nylon lock Nut M8 2 116 Spring Washer Φ8 2

85 Nylon lock Nut M10 18 117 Plug 48*22.7*R48 2

86 Nylon lock Nut M12 2 118 Button Φ8.1*7 10

87 Socket Set Screw 10-32*3.2 4 119 Flat Washer Φ9*Φ22*1.6 2

88 Plastic Cover Φ21*5.7 4 120 Right Short Shroud Retainer Plate 1

89 Plastic Washer Φ13*3 4
