─ 20 ─

AssemblyAssembly

STEP 7

1. Attach one Shroud (#37) to the Weight Stack Frame (#1) using:

four Φ13*3 Plastic Washers (#89) four Φ21*5.7 Plastic Covers (#88)

four Φ18*12 Connect Button (#60) four ST4.2*10 Self-Tapping Screws (#78)

2. Attach the Top Front Shroud & The Front Support (#39 & #40) to the Weight

Stack Frame (#1) using:

four Φ8*Φ20*23 Buttons (#59) three M5*16 Flat Philips Screws (#77)

3. Attach the Top Rear Shroud (#38) to the Weight Stack Frame (#1) using:

five Φ8*Φ20*23 Buttons (#59)

Note: Wrench Tighten Βolts and Nylon Lock nuts.

Here is the assembly instruction for Shor t Shroud !
