36 | English
1 609 929 W04 | (11/2/10) Bosch Power Tools
Permissible Workpiece Dimensions
Maximal workpiece sizes:
Minimal workpiece sizes
(= all workpieces that can be clamped left or
right from the saw blade with the supplied ma-
terial clamp 17):
170 x 45 mm (length x width)
Cutting capacity, max. (0°/0°): 89 mm
Replacing Insert Plates (see figure L)
The red insert plates 7 can become worn after
long use of the machine.
Replace defective insert plates.
– Bring the power tool into the working posi-
tion.
– Unscrew the screws 42 using the provided
Phillips screwdriver and remove the old in-
sert plates.
– Insert the new right-hand insert plate.
– Screw the insert plate as far as possible to
the right with the screws 42 so that the saw
blade does not come into contact with the in-
sert plate over the complete length of the
possible slide motion.
– Repeat the work steps in the same manner
for the left-hand insert plate.
Sawing
Cutting Off
– Firmly clamp the workpiece as appropriate
for its dimensions.
– Adjust the requested horizontal and/or verti-
cal mitre/bevel angle.
– Switch on the machine.
– Press lever 1 and slowly guide the tool arm
downward by handle 2.
– Saw through the workpiece applying uniform
feed.
– Switch off the machine and wait until the
saw blade has come to a complete stop.
– Guide the tool arm slowly upward.
Special Workpieces
When sawing curved or round workpieces,
these must be especially secured against slip-
ping. At the cutting line, no gap may exist be-
tween workpiece, fence and saw table.
Provide for special fixtures, if required.
Mitre/Bevel Angle Height x Width
[mm]
Horizontal Vertical at max.
height
at max.
width
0° 0°
89 x 89 60 x 130
45° 0°
89 x 59 57 x 89
0° 45°
58 x 85 38 x 120
45° 45°
38 x 76 38 x 76
OBJ_BUCH-1156-001.book Page 36 Thursday, February 11, 2010 12:08 PM
