10
K-Config - Getting to Know K-Config
4 Getting to Know K-Config
You are here:
Configuration Steps
Description
Section
Introduction
General information and system requirements
1
Planning
Carefully plan your controlled room
2
Installation
Install the Software
3
Introduction to K-Config
Get to know the K-Config main window, menus and quick access icons
4
Driver Manager
Define the Peripheral Device Drivers
5
Project Navigator
Define the Controlled Room
6
Port Manager
Assign the peripheral devices to the Master and Auxiliary device ports
7
Triggers
Activate the Triggers
8
Adding Actions
Describes how to add the various actions to a trigger
9
Connecting to a Device
Describes how to connect to a device, upgrade the firmware, read/write to the device
and so on
10
Following the installation, you can click the K-Config icon to open the software:
Figure 14: Opening K-Config
The Driver Database Notice appears if K-Config is opened for the first time:
Figure 15: Driver Database Notice
If you are opening K-Config for the first time, the driver data base is empty and you need to download the drivers. For
Kramer product drivers, click the link in this window to download the drivers from the Kramer Web site and then you
can import the drivers. In the same way download the drivers of other peripheral devices (see Section 4.1).
