TP-581T, TP-582T and TP‑582R - Connecting the Devices
11
8. Connect the 5V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 4).
5.2 Connecting the TP-582R
To connect the TP-582R as shown in the example in Figure 4, do the following:
1. Connect the HDMI OUT 1 connector to the first HDMI acceptor (for example,
LCD display 1).
2. Connect the HDMI OUT 2 connector to the first HDMI acceptor (for example,
LCD display 2).
3. Connect the ETHERNET RJ-45 connector to a network.
4. Connect the RS-232 9-pin D-sub connector to an RS-232 port (for example,
a projector).
5. Connect the IR 3.5mm mini jack to an IR sensor.
6. Connect S/PDIF RCA connector to a digital audio acceptor (for example, a
digital audio recorder).
7. Connect TOSLINK
®
connector to an optical audio acceptor (for example, a
digital audio recorder) (not shown in Figure 4).
8. Connect the LINE IN RJ-45 connector over CAT 5 twisted pair to the
TP-581T or TP-582T LINE OUT connector.
9. If required, acquire the EDID (see Section 5.6).
10. Connect the 5V DC power adapter to the power socket and connect the
adapter to the mains electricity (not shown in Figure 4).
