TP-581T, TP-582T and TP‑582R - Connecting the Devices

5.7 Acquiring the EDID

To acquire the EDID, connect the transmitter and receiver system as described in

Section 5.

Once the power is connected, the system acquires the EDID according to the

following priorities:

 If only one output is connected, the EDID is acquired from that output

 If both outputs are connected, the EDID is acquired from the output

connected to HDMI OUT 1

 If no output is connected, the default EDID is acquired

To acquire the EDID of a newly connected output:

1. Disconnect the power on the TP-582R.

2. Connect the new acceptor (to HDMI OUT 1, if two outputs are connected).

3. Connect the power.

The EDID is acquired only if the power is disconnected and then

reconnected
